CONNECTING TO GAS SUPPLY
The cooker is designed to match the depth of standard 600mm worktops.
An adapter backplate should, therefore, be fitted within the shaded area
shown to allow the cooker to be pushed fully to the wall.
Connection to the cooker should be made with an approved appliance flexible
connection to BS 669. A length of 0.9 to 1.25m is recommended. The length of
hose chosen should be such that when the cooker is in situ, the hose does not
touch the floor.
The temperature rise of areas at the rear of the cooker that are likely to come in
contact with the flexible hose do not exceed 70
o C.
32
INSTALLATION INSTRUCTIONS
40mm
30mm
220mm
70mm
635mm
450mm
GAS
BACKPLATE
POSITION
