Also known as Peritel, this standard provides a cheap multi-signal connector
to domestic TV and other video equipment.
Arrangement 1 is the original and allows for composite video input/output,
RGB inputs and stereo audio input/output.
Arrangement 2 allows for composite video input/output,and stereo audio
input/output.
Cation:The output of video and audio are always from turner of R F.
Arrangement 3 allows for composite video input, S-Video inputs,and stereo
audio input/output.
TV can auto check aspect ratio in scart.
Scart Connector Pinout Details
SCART arrangement 1
Pin Signal Signal level Impedance
1 Audio output B (right) 0.5V rms <1kohm
2 Audio input B (right) 0.5V rms >10kohm
3 Audio output A (left) 0.5V rms <1kohm
4 Ground (audio) - -
5 Ground (blue) - -
6 Audio input A (left) 0.5V rms >10kohm
7 Blue input 0.7V 75ohms
8 Function select (AV control)
High (9.5-12V)- AV mode
Low (0-2V) - TV mode
>10kohm
9 Ground (green) - -
