5
1.
Press a Stabilizer Endcap (11) onto each end of a
Stabilizer (10). Attach the Stabilizer to the front of
the Frame (1) with two M10 x 75mm Button Screws
(42) and two M10 Curved Washers (59).
1
10
59
59
59
59
42
1
5
25
24
1
42
11
11
11
11
10
2. Press a Stabilizer Endcap (11) onto each end of the
other Stabilizer (10). Attach the Stabilizer to the
back of the Frame (1) with two M10 x 75mm Button
Screws (42) and two M10 Curved Washers (59).
3. Identify the Left Pedals (24), which are marked with
“L” stickers. Using an adjustable wrench, firmly
tighten the Left Pedals
counterclockwise into the
Pedal Frame (5). Tighten the Right Pedals (25)
clockwise into the Pedal Frame. Important:
Tighten all Pedals as firmly as possible. After
using the exerciser for one week, retighten the
Pedals. For best performance, keep the Pedals
tightened.
3
2
To make assembly easier, read the information
on page 4 before you begin assembling the
exerciser.
