LOOSE PARTS LIST
1 Bolt (3/8-16 x 4-1/4 in.) .......................................2
2 Washer (3/8 in.) ....................................................6
3 Spacer (.38 ID) .....................................................2
4 Wheel ...................................................................2
5 Lock Nut (3/8-16) .................................................2
6 Handle Lock Pin ..................................................2
7 Lanyard ................................................................2
8 Lock Nut (1/4-20) .................................................2
9 Washer (1/4 in.) ....................................................2
The following items are included with the generator:
10 Rubber Foot ........................................................2
11 Bolt (1/4-20 x 1-1/2 in.) .......................................2
12 Flange Nut (5/16-18) ............................................2
13 Washer (5/16 in.) ..................................................2
14 Bolt (5/16-18 x 1 in.) ............................................2
15 Frame Support ....................................................1
16 Engine Lubricant..................................................1
Operator’s Manual (not shown) ...........................1
Key
No. Description Qty.
Key
No. Description Qty.
