Assembly, Rear – HONDA CV752A User Manual
Page 3
HEX. BOLT,
1.
Assemble the link pins to the A-frame
halves using
nuts, lock washers
and hex nuts.
2.
Join the frame halves together with the
spacing plate. Secure the plate at the front
only with the hex bolts, lock washers
and hex nuts. Finger-tighten the bolts.
3.
Assemble the frame angles to the A-frame
as
shown. Install the hex bolts, plain
washers, lock washers and hex nuts:
finger-tighten.
4.
Install the struts
first
at the rear of the
A-frame, and then at the
rear
of the frame
angles. Finger-tighten the bolts.
NOTE The frame
is
shown assembled for the
most common cutting position
The
cutting angle
is
determined by where the
struts are attached to the frame angles.
5.
Assemble a spring shank at positions
1
and 2-where frame angles attach to
A-frame-with existing hardware.
Assemble the remaining spring
shanks
as
shown.
Use
(thick) washers between
the springs and frame angles.*
6.
Align the springs and tighten all frame
and
spring bolts securely.
x
1
WASHER
HEX. BOLT,
x
1
LOCK WASHER
HEX. NUT
x
1
PLAIN WASHER
LOCK WASHER
HEX. NUT
FRAME
ANGLES
POSITION
1
HEX. BOLT,
x
1
PLAIN WASHER
LOCK WASHER
HEX. NUT
