43
13 13
Reference Materials
A. Fireplace Dimensions
42"
36"
40"
7"
12"
40"
24"
GAS
KNOCKOUT
GAS
KNOCKOUT
OUTSIDE AIR
COVER PLATE
42"
36"
40"
12"
24"
11"
20"
FRONT VIEW - BAY-40
END VIEW - BAY-40
TOP VIEW - BOTH MODELS
BOTTOM VIEW
BAY-40
FRONT VIEW - PIER-40
END VIEW - PIER-40
22½"
5¾"
½"
5¾"
22½"
3"
9½"
5 3 /
8
"
8¼"
44"
8¾"
5¼"
12"
17 5 /
8
"
47 1 /
8
"
47 1 /
8
"
Heat & Glo • BAY-40, PIER-40 • 34977 • Rev V • 11/08
