CONNECTING EXTERNAL AUDIO SOURCES
22
CONNECTING EXTERNAL AUDIO SOURCES
NOTE: To prevent damage to the speaker and distorted sound, set the volume control of the audio amplifier lower
and adjust the sound using the remote control fo the TV set.
The exact arrangement you use to connect the VCR, camcorder, laserdisc player, DVD player or HDTV Set Top
Box to your TV set is dependent on the model and features of each component. Check the owner's manual of
each component for the location of video and audio inputs and outputs.
The following connection diagrams are offered as suggestions. However, you may need to modify them to
accommodate your particular assortment of components and features. For best performance, video and audio
