1.3 Kit Components
Before beginning the installation of your NOS kit, compare the components in your kit with those shown in Figure 1 and listed in
Table 2. If any components are missing, please contact NOS Technical Support at 1-866-GOHOLLEY.
Table 2 NOS 2005 Mustang 02121NOS Parts List
Item Description Quantity NOS P/N
(1) Bottle Nut Adapter 1 16220NOS
(2) Bottle Valve Washer 1 16210NOS
(3) 10 lb. Bottle 1 14745NOS
(4) Bottle Mounting Bracket, Short 1 14126-SNOS
(5) Bottle Mounting Bracket, Long 1 14127-SNOS
(6) N
2
O Powershot Solenoid 1 16020NOS
(7) Powershot Fuel Solenoid 1 16080NOS
(8) Relay Wiring Harness 1 15604-SNOS
(9) 30 Amp Relay 1 15618NOS
(10) 4an – 1/8NPT Nitrous Filter (Blue) 1 15570NOS
(11) Fuel Filter (Red) 1 15571NOS
(12) 4AN – 1/8 NPT Fitting (Red) 1 17961-SNOS
(13) 0.016” Flare Jet 1 13760-16NOS
(14) 0.020” Flare Jet 1 13760-20NOS
(15) 0.030” Flare Jet 1 13760-30NOS
(16) 0.036” Flare Jet 1 13760-36NOS
(17) 3AN x 2 ft. Hose (Blue) 1 15060-1NOS
(18) 3AN x 2 ft. Hose (Red) 1 15060-2NOS
(19) 4AN – 16 ft. Hose (Blue) 1 15300NOS
(20) Nozzle Mounting Bung Nut 1 13713-SNOS
(21) Nozzle Mounting Bung 1 13715-SNOS
(22) Fogger Nozzle 1 13716NOS
(23) 8-32 x 5/16 Phillips Head Screws 4 16506-SNOS
(24) Solenoid Bracket 1 49R3002
(25) Washers 2 46R1421
(26) Purge Switch 1 15610NOS
(27) WOT/Window Switch 1 200R539A
(28) Fuel Pressure Sensor Assembly 1 40R827A
(29) Switch Panel Backing Plate 1 49R3003
(30) Switch Panel 1 89R693
(31) M5 x 50 mm Hex Head Screws 2 5R2218
(32) 4AN 7 1/4” in. 90° Hose 1 52R424
(33) Rocker Switch (on/off) 2 89R694
(34) 14 Gauge Blue Wire 8 ft. 1 15751-VSNOS
(35) 4AN Red Cap Plug 1 A1001-SNOS
(36) Basic Wire Pack 1 15612-VSNOS
Rocker Switch 1 15602NOS
15 amp Fuse 1 208R2
Microswitch 1 15640NOS
4-40 x 1 SL PAN HD M Screw* 2 15647-SNOS
4-40 Hex Nut* 2 15648-SNOS
1/4” Ring Terminal 3 15882-SNOS
Blue Female Spade Terminal .25 7 15885B-SNOS
Blue Male Spade Terminal .25 1 15886B-SNOS
Scotchlock 1 15891-SNOS
