20
V. APPENDIX A - SPECIFICATIONS
Data Rates
1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54, 72, 84,
150 and 300Mbps (with 2-stream on both ends)
Standards / Compliance
IEEE802.3, IEEE802.3u, IEEE802.11b,
IEEE802.11g, 802.11n 2.0
Regulation Certifications
FCC Part 15, ETSI 300/328/CE
Operating Voltage
5 V ± 0.25V
Status LEDs
LINK
Drivers
Windows 2000/XP/Vista
RF Information
Frequency Band
U.S., Europe and Japan product covering 2.4 to
2.484 GHz, programmable for different country
regulations
Media Access Protocol
Carrier Sense Multiple Access with Collision
Avoidance (CSMA/CA)
Modulation Technology
802.11g: OFDM (64-QAM, 16-QAM, QPSK,
BPSK)
802.11b: DSSS (DBPSK, DQPSK, CCK)
Operating Channels
11 for North America, 14 for Japan, 13 for
Europe
Receive Sensitivity (Typical)
• 2.412~2.472G(IEEE802.11b)
-91dBm @ 1Mbps
-90dBm @ 11Mbps
• 2.412~2.472G(IEEE802.11g)
-90dBm @ 6Mbps
-74dBm @ 54Mbps
• 2.412~2.472G(IEEE802.11N)
-90 dBm @ MCS 8
-65 dBm @ MCS 15
Available transmit power
• 2.412~2.472G(IEEE802.11b)
18dBm @1~11Mbps
• 2.412~2.472G(IEEE802.11g)
15 dBm @6Mbps
14 dBm @54Mbps
• 2.412~2.472G(IEEE802.11N)
15dBm
Antenna Configuration
2T2R Mode (detachable 2.4GHz
antenna/2.0dBi gain)
Networking
Topology
Ad-Hoc, Infrastructure
Security
WPA/WPA2 (AES, 64,128-WEP with
shared-key authentication)
Cisco CCS V1.0, V2.0 and V3.0 compliant
Physical
Form Factor
USB 2.0/1.1
Dimensions (HxWxD)
70(L) mm x 57.5(W) mm x 16(H) mm
Product Weight (excluding antennas)
55 g/ 2.0oz
Environmental
Temperature Range
Operating: 0°C to 50°C
Storage: -10°Cto 75°C
Humidity (non-condensing)
5%~95% Typical
