7pro – Heatcraft Refrigeration Products CHANDLER PTN User Manual
Page 7
7
PRO
3
Side Mount | Performance, Capacities and Specifications
Model
80° F Ambient
90° F Ambient
95° F Ambient
100° F Ambient
110° F Ambient
Box Temperature
35° F
38° F
35° F
38° F
35° F
38° F
35° F
38° F
35° F
38° F
PST070H6B*
7,066
7,414
6,860
7,198
6,641
6,968
6,442
6,759
5,678
5,957
PST090H6B*
9,196
9,644
8,928
9,363
8,643
9,064
8,383
8,792
7,389
7,749
PST131H6B*
13,244
13,946
12,859
13,540
12,448
13,107
12,074
12,714
10,643
11,207
PST147H6B*
14,982
15,702
14,545
15,245
14,081
14,758
13,658
14,315
12,039
12,618
Model PST
High/Medium Temperature | Air Defrost | Cooler Application
Model
80° F Ambient
90° F Ambient
95° F Ambient
100° F Ambient
110° F Ambient
35° F Box Temperature
PST066M6B*
7,066
6,860
6,641
6,442
5,678
PST086M6B*
9,196
8,928
8,643
8,383
7,389
PST124M6B*
13,244
12,859
12,448
12,074
10,643
PST141M6B*
14,982
14,545
14,081
13,658
12,039
Model PST
Medium Temperature | Electric Defrost | Cooler Application
Model
80° F Ambient
90° F Ambient
95° F Ambient
100° F Ambient
110° F Ambient
Box Temperature
0° F -10° F -20° F 0° F -10° F -20° F 0° F -10° F -20° F 0° F -10° F -20° F 0° F -10° F -20° F
PST034L6B*
5,584 4,052 2,659 5,031 3,651 2,395 4,746 3,444 2,260 4,366 3,168 2,079 3,726 2,704 1,774
PST051L6B*
7,683 6,025 4,377 6,922 5,428 3,943 6,530 5,121 3,720 6,008 4,711 3,423 5,126 4,020 2,920
PST057L6B*
8,873 6,748 4,609 7,994 6,079 4,153 7,541 5,735 3,918 6,938 5,276 3,604 5,920 4,502 3,075
PST077L6B*
11,769 9,079 6,694 10,602 8,179 6,030 10,002 7,716 5,689 9,202 7,099 5,234 7,852 6,057 4,466
Model PST
Low Temperature | Electric Defrost | Freezer Application
Model PST
Electrical Data | Specifications
* H for PSC, E for EC motor on evaporator section only.
1
See dimensional diagrams, page 8 and 9.
Model
Compressor
Model
Voltage
MCA MOPD Evaporator
CFM
Dimensions
Figure¹
Approximate Net Weight
lbs.
kg
PST070H6B*
RST64C1E
208-230/1/60
15�0
20�0
625
A
260
118
PST090H6B*
RST70C1E
208-230/1/60
15�0
20�0
625
A
265
120
PST131H6B*
CS10K6E
208-230/1/60
15�0
20�0
1,350
B
320
145
PST147H6B*
CS12K6E
208-230/1/60
15�0
20�0
1,350
B
325
148
PST066M6B*
RST64C1E
208-230/1/60
15�0
20�0
625
A
260
118
PST086M6B*
RST70C1E
208-230/1/60
15�0
20�0
625
A
265
120
PST124M6B*
CS10K6E
208-230/1/60
15�0
20�0
1,350
B
320
145
PST141M6B*
CS12K6E
208-230/1/60
15�0
20�0
1,350
B
325
148
PST034L6B*
CF04K6E
208-230/1/60
15�0
20�0
625
A
260
118
PST051L6B*
CF06K6E
208-230/1/60
15�0
20�0
625
A
265
120
PST057L6B*
CF06K6E
208-230/1/60
15�0
20�0
1,350
B
320
145
PST077L6B*
CF09K6E
208-230/1/60
20�7
35�0
1,350
B
325
148
