Parts and Functions
Indoor Unit
OUTLET
INLET
CONNECTING PIPING AND ELECTRICAL WIRING
DRAIN HOSE
Outdoor Unit
HSU-09HEA03/(BP)
HSU-12HEA03/(BP)
Actual inlet grille may vary from the one shown in the manual according to
the product purchased
Display board
Inlet
Air Purifying Filter
Horizontal flap
(adjust up and down air flow.
Don't adjust it manually)
Air filter(inside)
Inlet grille
Power plug
(inside)
Outlet
Anion generator
(inside)
(adjust left and right air flow)
Vertical blade
