A
Min. Max..
B D C
English
Components
Availability depending on Mod.Type
A Chest lid
B Lid seal
C Interior light
D Housing
E Storage shelf
F
Ventilation grille
G Control panel
H Divider
I
Pre-freeze shelf
K Hanging basket
L Compressor chamber
M Compressor (motor)
N
Drying filter
O Fan
P Condenser
Q Capillary tube
R Rear-wall condenser
S Stacking mark
T Outer-wall condenser
U Castors
V Handle
A
B
E
FIG. 1
D
Q
G
FIG. 2
R
L
M N O P
FIG. 3
C E
S H
I
T
F
k
A
B
C
A
B
C
D
Control panel versions
1st version with two light
Please underline the appropriate version for your appliance
Max..
2nd version with three light
A Temperature control (Thermostat)
B SUPER FREEZE
C ALARM
D CONTROL
yellow light
red light
green light
FIG. 4
A Temperature control (Thermostat)
B SUPER FREEZE
C CONTROL
FIG. 4a
FIG. 4b
yellow light
green light
If the indicator-lights on your appliance are laid out in a different way, the following always apply:
green = appliance operating; red = ALARM; yellow = SUPER FREEZE ON
U
V
A
B
C
OFF Min.
A
B
C
D
1
0
6
5
4
3
2
Max..
Min.
