Page 8
SKU 46055
Blade Mounting
Warning! Never attempt to mount a blade unless the Jigsaw is unplugged from the power
source.
1. Loosen the Bolt on the Blade Clamp (#21) with the Hex
Spanner (#32). Refer to
Figure 1 .
2. Insert the end (with holes) of the Blade between the
Blade Stock and the Blade Clamp. Hold the Blade level
while tightening the Bolt with the Hex Spanner (#32).
Note: To remove a Blade, loosen the Bolt and remove Blade.
Unpacking
When unpacking, check to make sure the parts listed on page 12 are included. If any
parts are missing or broken, please call Harbor Freight Tools at the number on the cover of
this manual as soon as possible.
SYMBOLOGY
Double Insulated
Canadian Standards
Association
Underwriters
Laboratories, Inc.
Volts Alternating Current
Amperes
No Load Revolutions
per Minute (RPM)
A
V ~
no xxxx/min.
Bolt
Blade Stock
Blade Clamp
Figure 1
Blade
