Exception TL200 W ood Stove

16

Exception Linkage Installation, cont'd

Figure 7

Top Lift Arm

Lift Lug

1/4 x 20" Self Locking Nut

1/4 x 20"
Button
head
Allenbolt

Drive Arm
Assembly

Outside
Damper Arm

Pivot Arm

Shoulder Pin
