10 REMOTE CONTROL FUNCTIONS

Remote Control Functions

Main Power On:

When the HK 3370

is in the Standby mode, as indicated by the

Power Indicator

3 glowing amber, press

this button to turn the HK 3370 on.

∫

Main Power Off:

When the HK 3370 is

turned on, press this button to place it in the
Standby mode. Note that in this condition,
the unit is still connected to AC Power.

Source Selectors:

Press these buttons

to select an input source for the HK 3370.

∂

Preset Up/Down:

When the tuner is in

use, these buttons scroll through the stations
that have been programmed into the HK 3370’s
memory. These buttons also control the track Skip
Up and Down on compatible Harman Kardon
compact disc players/changers.

≠

Transport Controls:

These buttons are

used to control Play, Play Forward, Play Reverse,
Stop, Pause and Record functions on compatible
Harman Kardon compact disc players/changers
and cassette tape decks.

Disc Skip:

These buttons do not have

any functions when controlling the HK 3370,
but they operate the Disc Skip functions of com-
patible Harman Kardon compact disc changers.

Sleep Button:

Press this button to place

the unit in the Sleep mode. Each press of the
button selects the amount of time that will
remain before the unit will automatically go
into the Standby mode, as shown in the

Information Display

Û, in the following

order:

Dimmer Button:

Press this button once

to reduce the brightness of the front panel dis-
play to half the normal intensity. Press it again
to turn the front panel display completely off.
When the display is completely off, press the
button to return to normal brightness.

Tuning:

Press these buttons to tune up or

down through a selected frequency band.

∆

Direct Button:

Press this button to

select a radio station by entering its frequency
using the

Numeric Keys

K. (See page 13

for more information.)

Numeric Keys:

These buttons serve as

a ten-button numeric keypad to enter tuner
preset positions or to tune stations directly.

Auto Preset:

When the tuner and FM

band have been selected, this button may be
used to automatically program the tuner presets
for all active stations. To start the auto preset
scan, press and hold the button. Note that the
MEMO and PRESET indicators will flash. After
a few seconds, the tuner will start to “look” for
active stations, as shown by increasing frequen-
cy numbers in the Information Display. Release
the button and note that the tuner will briefly
stop at each active station and add a preset
number to the memory. If the FM tuner finds
fewer than 30 FM stations with acceptable sig-
nal strength, the Auto Preset tuning will scan
two more cycles or until the remaining vacant
preset memory spaces have been filled with
those found in the first scan. The scan will stop
when all 30 preset memory spaces have been
filled or when three scans through the band
have been completed.

Secondary Control Cover:

This slid-

ing cover normally is in the “up” position so
that it hides the secondary controls. To access
these controls, place your thumb on the small
recessed area at the top center of the control,
and gently press the cover down and towards
you.

Clear Button:

This button is used to clear

preset memory information for the HK 3370’s
tuner. (See page 14 for more information on
tuner presets.)

Memory Button:

Press this button to

open a memory position that stores a preset
location for the HK 3370’s tuner. (See page 14
for more information on tuner presets.)

Master Volume:

Press these buttons to

raise or lower the HK 3370’s volume.

P. Scan Button:

Press this button to

automatically scan through the list of stations
that are programmed into the HK 3370’s tuner
memory. When the button is pressed, each pre-
set station will play for five seconds before the
next station is selected. Press the button again
when the desired station is heard to stop the
preset scan.

Mute Button:

Press this button to

momentarily silence the HK 3370.

FM Mode Button:

Press this button

when the tuner is in use in the FM band to
switch to monaural reception if the station is
weak and noisy. (See page 13 for more
information.)

†

Tuning Up/Down:

When the tuner is in

use, these buttons will tune up or down through
the selected frequency band. A brief (1⁄2 second)
press of the button will manually tune to the
next frequency increment, while pressing and
holding the button for a longer period will auto-
matically tune to the next station with a signal
strong enough for acceptable reception. These
buttons will also control Fast Forward and
Fast Reverse (or Rewind) for compatible
Harman Kardon compact disc players/changers
and cassette tape decks.

Speaker 1 Selector:

Press this button

to turn the speakers connected to the

Speaker 1

Output

terminals ‡ on or off.

√

Speaker 2 Selector:

Press this button

to turn the speakers connected to the

Speaker 2

Output

terminals ° on or off.

∑

Transmitter Window:

Point this area of

the remote toward the receiver when using the
remote.

min

OFF
