8 9
Washing sequence
Figure 3
Figure 4
Figure 5
Spin timer Wash timer Wash selector
(To set to below 2 minute,
first set to 5 minute then
turn it back. It can increase
the service life of the timer).
(standard current,
strong current)
(To set to below 1 minute,
first set to 2 minute then
turn it back. It can increase
the service life of the timer).
Water-filling selector
Wash
1.Water-filling selector
Set the water inlet selector at the "WASH" side.
(Figure 1)
2. Fill the water and add the dissolved washing
powder to make the water level reach the preset
position. (Figure 2)
Run washing program for some time to stir and
dissolve the powder completely.
3.Put in the laundries. If the water quantity is
insufficient, please add water.
4.Select the current.
Select the strength of the current according to
the laundries. (Figure 3)
5.Select the washing time
Select the washing time according to the laundries.
(Figure 4)
6.After washing, Set the "WASH SELECTOR" at
"DRAIN" in order to discharge the water. (Figure 5).
Water inlet
entrance
5
3
1
2
4
9
15
12
6
3
OFF OFF
Figure 1
SPIN WASH
Figure 2
9
15
12
6
3
OFF
Midway spinning
1.
2.
3.
Put the laundries into the spin tub evenly and smoothly.
Spin
Run the foam-removing spinning.
Push
Push
Proper Proper
Outer cover of
The spin tub
Inner cover of
The spin tub
The laundries
are slanting
Gland
No gland
(1) Put the gland in properly.
Please put in the gland properly even if the laundries quantity is small.
(2) Close the inner and outer cover of the spin tub.
(3) Spin for 1-2 minutes.
(1) Open the outer cover of the spin tub.
(2) Set the water-filling selector control
rod at the "SPIN" side. Fill water for
about 1 minute.
If the water quantity filled is too large,
the water may flow out from the wash
tub side. Please twist the water tap to
limit the water filling.
(3) Close the outer cover of the spin tub.
Spin for 1-2 minutes.
SPIN WASH
