8
1 Inlet selector
(1) Set inlet selector to Wash side. Figure 1
(2 )Adjust water level rod to a position as needed.
2 Fill water and add solved powder detergent until
water reaches a suitable level.
It begin to wash to dispense detergent uniformly.
3 Put in the wash load, and supplement water
as necessary.
4 Wash selector
Select soft or standard water flow
intensity according to wash load.
5 Select wash time
Select wash time according to wash load.
6 After completion of wash, please set drain
selector at Drain position.
INLET SELECTOR WASH SPIN
Intensity can be Soft,
or Standard)
Spin timer Wash timer Wash selector
(If to set less than 2 min,
you should first surpass 6 min
and then turn back.) If to set less than 1 min, in
order to ensure long service life,
please first surpass 2 min and
then turn back
Drain selector
Do not set drain switch
on Drain position during
washing)
Washing sequence
WASH TIMER WASH SELECTOR SPIN TIMER DRAIN SELECTOR
STANDARD
SOFT
OFF
DRAIN
3
4
1
2
OFF
5 3
6
9
12
15
OFF
Wash
Page 7
Figure 3
Figure 1
Figure 3
Figure 4
Figure 2
Figure 4
(Figure 5)
WASH TIMER
3
6
9
12
15
OFF
WASH SELECTOR
STANDARD
SOFT
Figure 5
DRAIN SELECTOR
DRAIN
OFF
