6
5. Remove the backing from the Wrench Clip (26). Press
the Wrench Clip onto the base of the Uprights (84) in the
indicated location. Press the Allen Wrench (29) into the
Wrench Clip.
84
26
29
5
6. Make sure that all parts are tightened before you use the treadmill. To protect the floor or carpet, place
a mat under the treadmill. Read and familiarize yourself with the ÒTROUBLE-SHOOTING AND MAINTE-
NANCEÓ section on page 11.
4. Remove the two Frame Guide Screws (9) from the left
side of the Frame (5).
Attach the Frame Guide (10) and the Frame Guide
Spacer (11) to the Frame (5) with the two Frame Guide
Screws (9) as shown. Note: Be careful not to over-
tighten the Screws. Make sure that the thick end of
the Frame Guide is at the bottom.
10
11
Thick End
5
9
4
