22
SECTION VI –
ELEMENT CHARTS
SINGLE PHASE ELEMENT CHART
Element Part #
Power (Watts) Immersion
Length
Element Resistance
(Ohms) 120V 208V 240V 277V 480V
CH-FO-358 ---- 3500 ---- ---- ---- 11 3/8" 12.36
CH-FO-408 ---- 4000 ---- ---- ---- 11 3/8" 10.82
CH-FO-508 ---- 5000 ---- ---- ---- 13 1/4" 8.65
CH-FO-608 2000 6000 ---- ---- ---- 13 3/8" 7.21
CH-FO-304 ---- ---- 3000 4000 ---- 9 3/4" 19.20
CH-FO-354 ---- 2500 3500 ---- ---- 9 3/4" 16.46
CH-FO-404 ---- 3000 4000 ---- ---- 11 1/2" 14.40
CH-FO-454 ---- ---- 4500 ---- ---- 11 1/2" 12.80
CH-FO-504 ---- ---- 5000 ---- ---- 11 1/2" 11.52
CH-FO-604 1500 4500 6000 ---- ---- 13 1/2" 9.60
TGB-1203-480 ---- ---- ---- ---- 2000 7 5/8" 83.23
TGB-1353-480 ---- 500 ---- 1000 3500 12 1/2" 47.56
TGB-2257L 2500 ---- ---- ---- ---- 9 5/8" 5.76
TGB-1207-240 500 1500 2000 2500 ---- 13 3/8" 28.80
TGB-1303-480 ---- ---- 990 3000 10 1/2" 55.49
TGB-1403-480 ---- ---- 1000 1350 4000 13 5/8" 41.62
TGB-2257-240 ---- 2000 2500 3500 ---- 10 5/8" 23.04
TGB-2257-480 ---- ---- ---- ---- 2500 13 1/4" 66.59
TGB-2457-277 ---- ---- ---- 4500 ---- 13 1/8" 17.05
TGB-2457-480 ---- ---- ---- 1500 4500 13 1/4" 36.99
TGB-2503-480 ---- 1000 ---- ---- 5000 9 3/4" 33.29
TGB-2507-277 ---- ---- ---- 5000 ---- 15" 15.35
TGB-2603-277 ---- ---- ---- 6000 ---- 15 1/2" 12.79
TGB-2603-480 ---- ---- 1500 2000 6000 15 1/2" 27.74
*Red wattage indicates the stamped element rating
Note: Element part numbers, ratings, and lengths are subject to change without notice.
3-PHASE ELEMENT CHART
Element
Part # Immersion
Length
Resistance (Ohms)
Hairpin 1
Φ
3
Φ DELTA
3
Φ WYE
2-38683N 13" 57.6 19.2 57.6 38.6
3-38683N 13" 43.2 14.4 43.2 28.9
4-38683N 13" 34.4 11.5 34.4 23.0
5-38683N 13" 27.9 9.3 27.9 18.7
6-38683N 13" 21.6 7.2 21.6 14.5
7-38683N 13" 17.1 5.7 17.1 11.5
8-38683N 13" 14.4 4.8 14.4 9.6
9-38683N 15" 12.1 4.0 12.1 8.1
10-38683N 15"
9.1 3.0 9.1 6.1
11-38683N 15" 7.5 2.5 7.5 5.0
