Parts Diagram
D
7
1.
Vehicle Frame
2.
Vehicle Body
3.
Seat
4.
Wheel - 2
5.
Gas Tank
6.
Footboard
7.
Exhaust - Inner Half - 2
8.
Exhaust - Outer Half - 2
9.
6 Volt Battery - 2
10.
Axle Bushing - 2
11.
Hex Bushing - 4
12.
Wheel Axle - 2
13.
Saddlebag - 2
14.
Steering Bushing - 2
15
Headlight - Front Half
16.
Headlight - Rear Half
17.
Handlebar - 2
18.
Sound Box
19.
Front Fork
20.
Handgrip - 2
21.
Round Bushing - 2
22.
Steering Stop
23.
Fork Axle
24.
Fork Cover
25.
Fender
26.
Shock - Inner Half - 2
27.
Shock - Outer Half - 2
28.
12 Volt Charger
29.
.354 Retainer - 2
30.
.437 Retainer - 4
31.
Battery Clamp
Not Shown
3
/
4
" Plastite Screw - 55
Label Sheet
5
2
28
3
16
19
17
13
23
6
12
7
8
1
21
27
12
22
29
15
4
20
24
14
29
18
31
9
26
30
14
4
25
11
10
30
11
Note: Some parts shown are assembled
on both sides of the vehicle.
