Dolphin® 7900 Series Mobile Computer User’s Guide 5 - 1
Using the Image Engine
Overview
The Dolphin 7900 terminal houses a compact image engine that instantly reads all popular 1D and 2D bar codes and supports
omni-directional aiming and decoding for greater flexibility in real-world settings. The image engine can also capture digital
images, such as signatures and pictures of damaged inventory. Images are saved in industry-standard file formats.
Image Engine Options
Dolphin 7900 terminals may be equipped with one of the following image engines.
Note: The IMAGETEAM 4300 SR image engine contains a high-visibility aimer that projects aiming brackets around the bar
code or image preview for maximum viewability. For details, see IMAGETEAM 4300 High Vis on page 5-4 and page 5-6 .
IMAGETEAM
™
4100 Standard Range (SR)
IMAGETEAM
™
4300 Standard Range (SR)
Code 8 mil Linear 10 mil PDF417 13 mil UPC 15 mil PDF417
15 mil Data
Matrix
35 mil MaxiCode
Working Range (.020cm) (.025cm) (.033cm) (.038cm) (.038cm) (.089cm)
Near 3.4 in. (8.6cm) 3 in. (7.6cm) 2.4 in. (6.1cm) 3.4 in. (8.6cm) 3.6 in. (9.1cm) 1.9 in. (4.8cm)
Far 7.5 in. (19cm) 8.9 in. (22.6cm) 12.4 in. (31.5cm) 11.1 in. (28.2cm) 6.4 in. (16.2cm) 12.9 in. (32.7cm)
IMAGETEAM
™
4100 Smart Focus (SF)
Code 6.6 mil PDF417 7.5 mil Linear 10 mil Linear 13 mil UPC 10 mil PDF417
15 mil Data
Matrix
Working Range (.017cm) (.019cm) (.025cm) (.033cm) (.025cm) (.038cm)
Near 2.7 in. (6.8cm) 2.4 in. (6cm) 2.1 in. (5.3cm) 2.2 in. (5.6cm) 2.1 in. (5.3cm) 2.2 in. (5.6cm)
Far 5.9 in. (14.9cm) 6.4 in. (16cm) 7.5 in. (19cm) 8.8 in. (22.3cm) 7.5 in. (19cm) 5.9 in. (14.9cm)
IMAGETEAM
™
4100 High Definition (HD)
