How to order replacement parts, Part identification chart – Healthrider HRT12920 User Manual
Page 27
111
1
Pulley Spacer
112
2
Shield Screw
113
2
Static Decal
114
1
Book Plate
115
1
Idler Pulley Bolt
116
1
Right Foam Grip
117
1
Console Base
118*
1
Latch Assembly
119
1
Right Fan Cover
120
1
Left Fan Cover
121
2
Motor Bushing
122
1
Idler Arm Nylon Washer
123
1
Hand Pulse Wire
124
1
Incline Bracket
125
1
Incline Motor Bolt (Bottom)
126
2
Hood Mounting Screw
127
1
Motor Isolator Plate
128
2
Cup Holder
129
2
1/2” Screw
130
2
Base Washer
#
1
12” Green Wire, F/Ring
#
1
8” Green Wire, F/Ring
#
1
10” White Wire, 2 F
#
1
4” Blue Wire, 2 F
#
1
User’s Manual
* Includes all parts shown in the box
# These parts are not illustrated
Key No. Qty.
Description
Key No. Qty.
Description
HOW TO ORDER REPLACEMENT PARTS
To order replacement parts, call our Customer Service Department toll-free at 1-800-999-3756, Monday through
Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be prepared to give
the following information:
• The MODEL NUMBER of the product (HRT12920)
• The NAME of the product (HealthRider
®
L600i treadmill)
• The SERIAL NUMBER of the product (see the front cover of this manual)
• The KEY NUMBER and DESCRIPTION of the part(s) (see the PART LIST on pages 26 and 27)
PART IDENTIFICATION CHART
Use the chart below to identify small parts during assembly.
U-Base Nut (51)–2
Extension Screw
(50)–8
3/4” Silver Screw
(101)–4
Plastic Fastener
(75)–4
1/2” Screw
(129)–2
Base Washer (130)–2
2” Bolt (26)–4
3” Bolt (23)–2
