Hanger Kit Installation
HANGER
HANGER
GENERATOR
SIDE
HANGER BRACKET (2)
8
16 mm FLANGE BOLT (4)
280 mm (11 in)
Position the hanger at the generator’s balance point as shown below.
Fit the end tabs of the hanger through the bracket slots, and bolt the
brackets to the hanger and tighten securely.
1.
2.
