Technical data – Husqvarna 130BT User Manual
Page 13

English
13
MODEL
130BT
350BT
370BTS
380BTS
Dimensions (L x W x H) mm
295x387x432
351x446x479
365x464x485
410x509x497
Dry Weight kg (lbs) (including pipe)
6.75
10.2
12
13.2
Dry Weight kg (without accessories)
6.1
9.5
11.2
12.4
Fuel Tank Capacity liter
0.9
1.25
1.75
2.13
Engine Type
Air cooled 2-cycle gasoline engine
Piston Displacement cu. cm
29.5
50.2
64.9
71.9
Air Filter
Single stage fil-
ter
Single stage fil-
ter
(half wet)
2-stage fresh flow filter system
Carburetor (Diaphragm) valve type
Rotary
Ignition System
CDI
Digital Ignition
Spark Plug
NGK CMR7H
Muffler
Spark arrester equipped
Idle speed rpm
3000
2200
2000
Operating Engine Speed rpm
3000 to 6700
2200 to 6100
2000 to 6900
2000 to 6700
Fuel Consumption liter/h
0.58
1.04
1.6
1.85
Air Volume (w/std Pipe) cu. m/min
10.2
14
16
19.4
Air Volume (@ housing) cu. m/min
12.2
19.6
21.0
25.9
Air velocity m/sec (Maximum)
65
80
88
90
Noise emission (see note 1)
Sound power level , measured dB (A)
102
104
110
109
Sound power level , guaranteed L
WA
dB (A)
102
104
110
Sound levels (see note 2)
Equivalent sound pressure level at the operator’s ear,
measured according to EN15503 dB(A)
91
95
96 (ISO7917)
97
Vibration levels (see note 3)
Equivalent vibration levels (a
hveq)
at handle, measured
according to EN15503 m/s
2
2,5
2,1
4,0
2,1
Technical data
• The data shown above are those in the case of one straight pipe.
• Specifications are subject to change without notice.
Note 1: Noise emissions in the environment measured as sound power (L
WA
) in conformity with EC directive 2000/14/EC. Reported sound
power level for the machine has been measured with the original attachment that gives the highest level. The difference between
guaranteed and measured sound power is that the guaranteed sound power also includes dispersion in the measurement result and the
variations between different machines of the same model according to Directive 2000/14/EC.
Note 2: The equivalent sound pressure level value is calculated with a work cycle of a duration of 1/7 for idling and 6/7 for racing. Reported
data for equivalent sound pressure level for the machine has a typical statistical dispersion (standard deviation) of 1 dB(A).
Note 3: The equivalent Vibration total value is calculated with a work cycle of a duration of 1/7 for idling and 6/7 for racing. Reported data
for equivalent vibration level has a typical statistical dispersion (standard deviation) of 1 m/s
2
.
