English Instruction for use
5
a) No objects (dishcloths, parts of food packaging etc.) are caught between the door and cabinet
b) Door seal or door hinges are not damaged or soiled (also see section on "Cleaning and care")
The power cable of the oven is not led underneath the oven base, which does get hot, and does not
come into contact with sharp edges or hot objects.
The power cable does not extend into the other kitchen work areas.
The power cable does not drop from the work top and nobody can get caught in it.
The power cable does not come into contact with moisture(e.g. when wiping the work top or rinsing).
The power plug is easily accessible and can quickly be unplugged in case of danger
.
The power plug is always firmly inserted in the socket and loose contact cannot cause any fire hazards.
Slack power plugs or sockets must be immediately repaired by a skilled electrician.
No curtains are nearby.
When operating the microwave oven for the first time, make sure that:
6 Using the microwave oven
1. Before switching on the appliance, you should familiarizes yourself with the following guidelines:
Never operate the oven when it is empty otherwise it could get damaged. .
Within sealed dishes overpressure can quickly develop and thus cause the dish to burst. This leads to
potentially serious accidents.
Never heat liquids or food(s) in sealed dishes
The following items are also liable to burst due to developing overpressure: eggs in shells,
nuts in shells or any food(s) vacuum packed in plastic foil.
Therefore, always pierce raw eggs on two sides and remove the foil or at least cut it open on one whole
side, before you put it into the oven. Remove nutshells.
To prevent the oven from being operated inadvertently without contents, always leave a glass of
water in the cavity when the appliance is out of use.
Otherwise sparking may occur inside the oven and the appliance could consequently get damaged.
During operation your microwave oven may present scalding hazards in the following components:
Should the use of aluminium foil be recommended in a recipe, make sure that it tightly adheres to
the cookware or food and a gap of at least 2.5 cm is left between the aluminium foil and the
cooking compartment walls.
In order to ensure that the seal is constantly protected adequately against hazardous escap-
ing microwaves,
always make sure that:
Do not touch - scalding hazard
on the door - glass panel
on the lateral air vents
on the underside of the oven
2. Prevention of smoke or fire in the microwave oven
English Instruction for use
8
If food(s) overheats, smoke may develop or smouldering may start inside the oven.
Food(s) with a high sugar or fat content are particularly prone to this hazard.
KEEP WARM
Touch the pad, 00:00 flashes in the display, Enter/ /Time indicator will flash, set time 05:00
and touch START pad, the microwave begins to work and the time counts down.
indicator lights. When the cooking is finished, the buzzer of control panel will remind you
with three short ticks, and the screen display .It will return to the enter states
automatically in 10seconds.
GRILL/COMBI
DEFROST 3 MENU
Enter kg
Enter
KEEP WARM
Time
Enter Time
CHILD SAFETY LOCK
Press and Hold the PAUSE/STOP pad until it locks the controls, and in the right of the
display shows L .
Press and Hold the PAUSE/STOP pad until it unlocks the controls. It returns to the enter state.
Note: To lock or unlock the child safety lock function, the buzzer of the microwave oven will beep
twice.
1
2
3
DEFROST 3 MENU
Menu Touch Times Display
MEAT
POULTRY
Note: If you want to temporarily stop an AUTOMATIC EXPRESS COOKING process, press the
PAUSE/STOP pad once and then you can start the cooking by press START; or press the
PAUSE/STOP pad twice to cancel the cooking program altogether, then the microwave oven
returns to the electrified state.
3
1
2
1
2
3
1
2
3
1
2
3
POULTRY
MEAT
FISH/SEAFOOD
FROZEN DINNER
0.4kg
0.8kg
1.0kg
0.2kg
0.5kg
1.0kg
0.7kg
1.0kg
1.2kg
0.2kg
0.4kg
0.6kg
14 1 0 "
20 30"
25 10"
5 40"
8 30"
11 00"
5'00
7 0 0
12 00
5 25"
7 00"
8 10"
"
"
"
'
'
'
'
'
'
'
'
''''' '
'
'
'
FISH
Note: the weight you input is the multiple of 100g,
you can setup freely from 0.1kg to 3kg.
DEFROST 3 MENU
1.For example to defrost poultry of 0.1kg :Touch the pad two times, the Enter/ /kg indicator
will flash, input the weight 0.1 , then touch START pad, the oven begins to work. When the
cooking is finished, the buzzer of control panel will remind you with three short ticks, and
the screen displays
. It will return to the enter states automatically in 10 seconds.
GRILL/
COMBI
Enter Cook Time
Enter Cook Time
Small quantities and thin pieces can be browned in the grill function, and it is recommended
to cook larger quantities and thicker pieces in the COMBINATION MICROWAVE & GRILL.
The grill has three power levels. Select the power level most suitable
for the kind of food
to cooked.
For example: suppose you want to cook something for 5 minutes on power level C-1.
1.Enter the power level by touching
GRILL/COMBI twice.
The display shows C-1 and Enter/Cook/Time/ indicator will flash.
2.Input cooking time 05:00.
3.Now touch START keypad, the oven start working and the time you setup will count
down. Indicator will light.
When the cooking is finished, The display shows , the buzzer of control panel will
remind you with three short ticks. Then it returns to the enter states automatically in
10 seconds. Or If you want to reenter start states, please touch PAUSE/STOP pad twice.
Before your first use, please unveil the film on the surface of the door joining group.
on the top of the oven
