HONDA 2008 - Manual (Page 336)

No. No. Circuits Protected Circuits Protected Amps. Amps.
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
TPMS
Headlight Low Beam
Not used
Not used
Moonroof
Door Lock
Front Left Power Window
HAC Option
Rear Accessory Socket
Accessory
Front Right Power Window
Accessory Power Socket on
the Center Table
Rear Right Power Window
Rear Left power window
ACC Radio
ACC Key lock
HAC
Daytime Running Lights
Front Wiper
Power Window Relay
Fuel Pump
ACG
ABS/VSA
Heated Seats
Front Fog Lights
Not used
Rear Wiper
ODS (Occupant Detection
System)
Meter
SRS
Right Headlight High Beam
Left Headlight High Beam
Small Light (Interior)
Small Light (Exterior)
Right Headlight Low Beam
Left Headlight Low Beam
Main Headlight High Beam
Small Lights MAIN
7.5 A
15 A
10 A
7.5 A
(15 A)
(20 A)
10 A
7.5 A
7.5 A
10 A
10 A
10 A
7.5 A
7.5 A
10 A
10 A
20 A
15 A
7.5 A
20 A
(20 A)
20 A
20 A
(20 A)
15 A
15 A
20 A
(15 A)
20 A
20 A
7.5 A
7.5 A
10 A
7.5 A
30 A
: If equipped
Fuse Locations
330
INTERIOR FUSE BOX
