LOCATION OF CONTROLS
LOCATION
OF
CONTROLS
Details are described on the page shown by the number attached to the part name
(example: ).
Front view illustration
Rear view illustration
FRONT PANEL JACKS AND CONNECTIONS
The front panel jacks are provided as a convenience to allow you to easily connect a
camcorder or VCR as shown in the following examples.
Front panel connections illustration
NOTE:
• Completely insert the connection cord plugs when connecting to front panel jacks. If you
do not, the played back picture may be abnormal.
