No# Description
QTY
1
Corner Support
4
2
Casters Bracket
2
3
Pad Bracket
2
4
Pad Knob
2
5
Pad Cover
2
6
Plastic Pad
2
7
2" Swivel Caster
2
8
3" Wheel
2
9
Screw Bolt
2
10
Rivet
2
11
Hex Head Screw M8 x 50
16
12
Hex Head Bolt M8 x 55
4
13
Flash Washer M8
2
14
Wing Nut 1/2"
2
15
Hex Nut 3/8” - 16NC
4
16
Nylon Lock Nut M8
20
DIAGRAM
