— 8 —
English
SPECIFICATIONS
Operating pressure 70 – 120 psi (4.9 – 8.3 bar 5 – 8.5 kgf/cm 2 )
Dimensions 16 - 15/16" Ч 14 - 3/32" Ч 4 - 47/64"
Length
× Height × Width
(430 mm
× 358 mm × 121 mm)
Weight 8.8 lbs (4.0 kg)
Nail capacity 56 – 84 nails
.095 ft 3 /cycle at 100 psi
Air consumption (2.7 ltr/cycle at 6.9 bar)
(2.7 ltr/cycle at 7 kgf/cm 2 )
Air inlet 3/8 NPT Thread
NAIL SELECTION
Only nails shown in the Table below can be driven with this Nailer.
Paper collated strip nails Min. Max.
Clipped-head nails
ACCESSORIES
WARNING
ⅷ Accessories other than those shown below can lead to malfunction and resulting injuries.
STANDARD ACCESSORIES
1 Eye protector 1
2 Allen wrench for M8 screw 1
3 Allen wrench for M6 screw 1
4 Allen wrench for M5 screw 1
5 Allen wrench for M4 screw 1
6 Nose Cap 1
.113"
(2.9 mm)
.266"
(6.8 mm)
2" (50 mm)
.148"
(3.8 mm)
.300"
(7.6 mm)
3-1/2" (90 mm)
1 2 4 3 6 5
