Remote Sensor Battery Installation:
1. Loosen the 4 screws securing the battery cover with a small screwdriver
(included) and remove. Insert 2 alkaline AAA batteries according to the polarity
direction indicated.
2. Place the home receiver (SoundSpa Premier) as close as possible to the remote
sensor. This will help with synchronization between the two units.
NOTE: Once you are ready to position your remote sensor and home
receiver, ensure that the distance is not outside the effective transmission
range (100 feet). Some building materials and location of the home receiver
or remote sensor can affect transmission quality and range. Try various
locations for best results.
3. Press the C/F button inside the remote sensor to change between º C and º F.
(The remote sensor is preset on º F.)
4. Press the TX button inside of the remote sensor to verify the reception.
5. Replace the cover and tighten the 4 screws.
NOTE: It is recommended to test the units next to each other to ensure that
both the remote sensor and home receiver are properly synchronized.
Remote Sensor Mounting Instructions
The Remote Sensor comes with a table stand or can be wall mounted.
Table Stand -
Simply fold out the attached stand from the mounting bracket.
Wall Mounting -
Set a screw in the desired hanging location and mount. A screw and wall anchor
have been included for your convenience.
NOTE: Keep the remote sensor out of direct sunlight and rain.
Do not mount on metal surface.
Remote Sensor Low Battery Indication
Low battery indication is available for the main unit and the remote sensor.
A battery life “
” icon will display on both. Replace the batteries as necessary
and follow the setup procedure.
MAINTENANCE AND CARE INSTRUCTIONS
• Extreme temperatures, shock or areas of unusual vibration should be avoided
to prevent damage to the units.
• Clean the units using only a soft, damp cloth to wipe. Do not use solvents,
abrasives, detergents or other strong cleaning agents. After cleaning, wipe
surfaces with a dry cloth.
• Do not submerge units in water or other liquids.
• Do not subject the units to extremely severe temperatures - DO NOT PLACE
UNITS INTO OVENS, FREEZERS or MICROWAVE UNITS.
NOTE: Opening the housing (other than the battery compartment) of the
Remote Sensor or the SoundSpa Unit will invalidate your warranty. Do not
attempt to repair this unit - There are no consumer serviceable parts.
TROUBLE SHOOTING
Indoor and Outdoor temperatures do not match when placed next to
each other -
The sensor is manufactured to be +/- 2 degree in accuracy under normal
conditions. So it is possible to have up to four degrees difference shown on
the separate temperature sensors (one could be “+2 degree” and the other
“-2 degree”. Additionally, the calibration curve is different between the two
units because of the greater temperature range of the outdoor sensor. Errors
are usually noted on the extreme ends of the temperature ranges.
SoundSpa unit is not accepting remote transmissions -
The units may not be properly synchronized or the batteries may need to
be replaced. See “USING OUTDOOR TEMPERATURE” section for detailed
instructions. With the two units next to each other, attempt synchronization.
Remember to always place the remote sensor within the effective transmission
range and away from large metal surfaces.
