4
How to Assemble
1. Place base on countertop.
2. Insert drip pan. Make sure the openings in the base and drip
pan line up for the power cord.
3. Place support rod in small indentations in drip pan.
4. Place the cord receptacle end of the
heating element through opening in drip
pan. Make sure the notched edge is
facing down. Position notch over edge
in drip pan opening, as illustrated.
When properly assembled the heating
element will rest on the support rod.
5. Place rack on top of assembled grill.
6. Attach power cord to cord receptacle.
Rack
BEFORE FIRST USE: Wash the rack, support rod, drip pan,
and base in hot, soapy water. Rinse and dry thoroughly.
Power Cord
Power Cord
Openings
Heating Element
Cord Receptacle
Base
Drip Pan
Variable Heat
Power Cord
(Available on
selected models.)
Offers High, Low,
and Off settings.
Parts and Features
Cord
Receptacle
Notch
5
Correct Amount to Grill Overloaded Grill
Support
Rod
How to Grill
DO NOT OPERATE THIS GRILL WITHOUT DRIP PAN IN PLACE.
During the first use of the grill some smoke and odor will be
noticed. This is normal with heating appliances and will not
occur after several uses.
1. Assemble grill as instructed above.
2. Always attach power cord to cord receptacle first. Then place
plug into outlet.
3. Preheat grill for 10 minutes. Never leave the grill unattended
when using.
4. For best performance, do not cover more than 75% of the
rack surface with food.
