ELECTRONIC VIEWFINDER
14
ELECTRONIC VIEWFINDER
Set the viewfinder to the position shown in the figure when carrying the camcorder or
storing it in the carrying case.
Turn the viewfinder to the position shown below when shooting pictures.
1. Turn the viewfinder
2. Turn the eyepiece.
You can adjust the position and angle of the viewfinder so you can see through it
easily.
Cautions:
• Do not force the viewfinder to rotate completely around. This will damage the viewfinder
and/or camcorder.
• When pulling the viewfinder out or returning it to its original position, hold the viewfinder
by the swivel selection. Do not hold the diopter control side.
