Hyundai H- CDM8039 - Manual (Page 27)

27
Specification
General
Power supply
12 V DC
Current consumption max. 10A
Maximum power output 50 W x 4 channels
Dimensions (L x W x H) 178 x 165 x 50 mm
Working temperature range -10º - +60º
ESP 40 sec. ESP for Audio-CD, 120 sec ESP for MP3, 300 sec ESP for WMA
FM Stereo Radio
Frequency range
65 – 74/87.5 - 108.0 MHz
Usable sensitivity 2.8 µV
Preset memory stations 24
MW and LW section
Frequency range
522 kHz - 1620 kHz
Preset memory stations 12
Audio specification
Maximum output
2 Vrms (+/- 3 dB)
Frequency response 20 Hz - 20 KHz
S/N ratio (A-vtd) 50 dB
DSP sound effect Classic, Rock, Pop, Flat
Line out
Output
2 channel RCA line-out (2V)
Specifications are subject to change without notice. Mass and dimension are approximate.
