Parts and functions
6
Front panel the TV set
Video 1
VIDEO IN jack
AUDIO IN (L/R) jacks
L-AUDIO-R
TV/AV
MENU
VOL-
VOL+
CH-
CH+
VIDEO
TV/AV
switching
MENU
Volume
decrease/
increase
Channel
down/up
Signal
Receiver
Indicator light
Power Switch
Power Indicator
and remote
receiving window
Power Button
TV/AV
MENU
V+
V-
CH-
CH+
TV/AV
MENU
V+
V-
CH-
CH+
Volume
down
Volume
up
Channel
down
Channel
up
Menu
Input
source
display
HTF201
HTR13/HTR20/HTF20
