39
REPAIR PARTS
DECALS
SNOW THROWER - MODEL NO. 924SB-XLS (96193003200), PRODUCT NO. 961 93 00-32
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
KEY PART
NO. NO. DESCRIPTION
1 532 18 10-37 DECAL, DANGER
2 532 42 10-50 DECAL, HUSQVARNA
3 532 18 10-35 DECAL, DANGER, DEFLECTOR
4 532 18 10-42 DECAL, DANGER
5 532 42 10-49 DECAL, HUSQVARNA, 924SB-XLS
6 532 18 10-33 DECAL, INSTRUCTION
7 532 18 37-30 DECAL, REMOTE DEFLECTOR
9 532 41 54-75 DECAL, SPEED CONTROL
11 532 41 53-99 DECAL, LH TRIGGER
12 532 41 53-98 DECAL, RH TRIGGER
- - 532 42 07-89 OWNER’S MANUAL, ENGLISH
- - 532 42 07-90 OWNER'S MANUAL, FRENCH
