Page 3

background image

SKU 98399

For technical questions, please call 1-800-444-3353.

Page 3

Figure 3

4.

To release the material that has been picked

up by the Magnetic Sweeper, place Housing

(1) over a trash can or desired debris des-

tination. Pull up on the Housing Handle as

shown in

Figure 3, above.

please note: Move the Sweeper away from

the debris before releasing the Housing

Handle or it will pick up the debris again.

cleanIng and maIntenance

BeFore each use,

1.

inspect the general

condition of the Floor Sweeper. Check for

loose screws, misalignment or binding of

moving parts, cracked or broken parts and

any other condition that may affect its safe

operation.
aFter use,

2.

clean external surfaces of the

Sweeper with clean cloth.

record serial number here:

note: If product has no serial number, record

month and year of purchase instead.

note: Some parts are listed and shown for illustra-

tion purposes only, and are not available

individually as replacement parts.

please read the FollowIng careFullY

THE MANUFACTURER AND/oR DISTRIBUToR HAS PRovIDED

THE PARTS LIST AND ASSEMBLy DIAGRAM IN THIS DoCUMENT

AS A REFERENCE TooL oNLy. NEITHER THE MANUFACTURER

oR DISTRIBUToR MAKES ANy REPRESENTATIoN oR WARRANTy

oF ANy KIND To THE BUyER THAT HE oR SHE IS qUALIFIED To

MAKE ANy REPAIRS To THE PRoDUCT, oR THAT HE oR SHE

IS qUALIFIED To REPLACE ANy PARTS oF THE PRoDUCT. IN

FACT, THE MANUFACTURER AND/oR DISTRIBUToR ExPRESSLy

STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHoULD

BE UNDERTAKEN By CERTIFIED AND LICENSED TECHNICIANS,

AND NoT By THE BUyER. THE BUyER ASSUMES ALL RISK AND

LIABILITy ARISING oUT oF HIS oR HER REPAIRS To THE oRIGINAL

PRoDUCT oR REPLACEMENT PARTS THERETo, oR ARISING

oUT oF HIS oR HER INSTALLATIoN oF REPLACEMENT PARTS

THERETo.

part

description

Qty.

1

Housing

1

2

Wheel

2

3

Handle

1

4

Bolt/Washer

2 sets

5

Handle Base

1

6

Housing Handle

1

7

Pan Head Bolt

1

parts lIst & assemBlY

dIagram

5

7

6
