>10mm

About less than 2mm after twisting

Figure 3

Connection between the water inlet hose jointer and the water faucet

Bushing

About 4mm before twisting

2. Loosen the screw till the water faucet can be accessed. Put the jointer of the water inlet hose on the faucet.
See to Figure 2. (If the faucet is too large and the jointer can not be set on the water faucet, please loosen
the four screws and take out the bushing in the jointer. The front end of the faucet must be smooth,
otherwise it may leak water. See to Figure 3.)

1.

Press the lower end of the lock lever and push down the slider. Take off the water inlet hose jointer from the

water inlet hose component. See to Figure 1.

Water faucet,not suitable

Install the water inlet hose

Screw

It is required that the front end shall be longer than 10mm.
The exit end face of the faucet shall be flat and smooth. If not please file it to avoid leakage.

remark: Before installation, the threading is 4mmabove the upper surface of the nut.

After installation, the threading is 2mm above the upper surface of the nut. See to figure 6.

Figure 6

Sign plate

4 Take off the nameplate. Twist the fastening nut as per the indication of the figure
to seal up the exit end face of the faucet. See to Figure 5.

Figure 2

Screw nut

Screw knife

3.

Fasten the four screws evenly. See to Figure 4.

water inlet hose jointer

Figure 5

Outlet end surface

Slider

Figure 1

Water faucet,suitable

water inlet hose

Figure 4

Lock level

Reserve, remain time digitron

It displays "--" during detecting.
It displays remained reserve time (hour).
It displays total remained time (min). If the total time
exceeds 99 minutes, it uses "A" on tens digit to
represent100 minutes, and uses "b" to represent 110
minutes. E.g. "A3" represents 103 minutes.
It displays abnormal symbol in abnormal situation.
(See to Page15)

"Program" button

Standard Common washing

Following full-auto program is available

Program

Application

Tub dry

Confirm the water faucet

Process

Process

"

"

Process button

"Power" button

Push the "power" button to switch on the power.
Under power-on mode, push it to switch off the power.
Push the "power" button to switch on the power. If
the "start/pause" button is not pushed, the machine
will switch off the power automatically after 5 minutes.

Heavy

Quick wash

Soft wash

Avoid growing mildew on the
outer tub and the inner tub

Soak

Wash

Rinse
Spin

Quick wash

Soft wash

Heavy

Standard

Tub dry

Washing for coverlet, bigger ,heavy

thickness laundries

Washing for silk textiles slap-up

laundries

With it you can select one or
several processes of soak,
wash, rinse and spin.

10 min quick wash for little clothes
