FRONT PANEL JACKS AND CONNECTIONS
18
FRONT PANEL JACKS AND CONNECTIONS
The front panel jacks are provided as a convenience to allow you to easily connect a camcorder
or VCR as shown in the following examples:
Front Panel Jacks Examples
NOTE: Completely insert the connections cord plugs when connecting to front panel jacks. If you
do not, the picture that is played back may be abnormal.
