Hafler P1500 User Manual
Page 20
DESIGNATOR VALUE
PART #
CR14
BAV99L Dual Diode
SS-260SM
CR15
BAV99L Dual Diode
SS-260SM
U1
TL072CD Dual Opamp SS-143SM
U2
TL072CD Dual Opamp SS-143SM
U4
LM339 Comparator
SS-730SM
U5
LM339 Comparator
SS-730SM
Power Switch
SWH-1009
IEC Connector
CC-0852
IEC Line Cord
FAH-146
Dual Binding Post
CC-0867
P3000 Transformer
TT-1531
F2
Fuse, 1A Fast
FS-1592
F3
Fuse, 1A Fast
PS-1592
Line Fuse
Fuse, 5A Slo Blo
FS-005SB
DESIGNATOR VALUE
PART #
C21
10
µ
F, 16V
CER-106SM
C22
10
µ
F, 16V
CER-106SM
C23
0.47
µ
F, 50V
CYV-474
C24
0.47
µ
F, 50V
CYV-474
C25
0.1
µ
F, 50V
CDS-104CCDB
C26
1
µ
F, 50V
CER-105C-024
C28
47
µ
F, 16V
CER-476-024
C29
10
µ
F, 50V
CER-106C-024
C30
0.1
µ
F, 50V
CDS-104CCDB
C31
0.1
µ
F, 50V
CDS-104CABB
C33
0.1
µ
F, 50V
CDS-104CCDB
C35
47pF, 200V
CM-470-024
C36
22pF, 200V
CM-200-024
C112
100
µ
F, 25V
CER-107A-024
C113
100
µ
F, 25V
CER-107A-024
C114
100pF, 50V
CDS-101CAAA
C115
100pF, 50V
CDS-101CAAA
C116
0.047
µ
F, 50V
CYV-473
C119
0.1
µ
F, 100V
CY-104
C120
0.1
µ
F, 100V
CY-104
Q1
MMBT3904LT1
SS-0792
Q2
LM-317
SS-239
Q3
LM-337
SS-240
Q4
2SK1058
SSH-741T
Q5
2SJ162
SSH-740T
Q6
MMBT5088L
SS-0114
Q7
MMBT5088L
SS-0114
Q8
MMBT3904LT1
SSS-0792
Q9
MPS-A56
SS-101A
Q10
MPS-A56
SS-101A
Q11
MPS-A06
SS-102A
Q12
MPS-A06
SS-102A
Q103
MMBTA06L
SS-102SM
Q104
MMBT3906LT1
SS-0791
Q105
MMBT3906LT1
SS-0791
Q115
2SK1058
SSH-741T
Q116
2SJ162
SSH-740T
CR1
Red LED
SS-741
CR2
Red LED
SS-741
CR3
Red LED
SS-741
CR4
Green LED
SS-740
CR5
MMBD914L Diode
SS-803SM
CR6
MMBD914L Diode
SS-803SM
CR7
MMBD914L Diode
SS-803SM
CR8
MMBD914L Diode
SS-803SM
CR9
Bridge Rectifier 15A
SS-0801
CR10
Bridge Rectifier 1.5A
SS-0800
CR11
BAV99L Dual Diode
SS-260SM
CR12
BAV99L Dual Diode
SS-260SM
CR13
MMBD914L Diode
SS-803SM
Parts List Modifications for
P1500U 120VAC, 60Hz
– 11 –
!
!
!
!
!
!
!
!
!
!
!
!
Components marked with this symbol are safety critical
and should only be replaced with identical components.
!
Los componentes marcados con el simbolo son
imprescindibles para la protección del equipo, por lo
cual que solo sean reemplazados por los mismos
componentes.
!
!
Les componsants marqués du symbole sont indis-
pensables à la sécuritée et ne peuvent être remplacés
qu'avec des composants identiques.
!
!
Bauteile, die mit einem gekenzeichnet sind, sind
sehr wichtig und dürfen nur mit den orginal Ersatzteilen
ausgetauscht werden.
!
!
I componenti contrassegnati da sono critici per la
sicurezza e devono essere rimpiazzati solo con ricambi
di valore identico.
!
C3
3300
µ
F, 63V
CERS-338E
C5
3300
µ
F 63V
CERS-338E
C35, 36
Not Used
CR9
Bridge Rectifier, 8A
SS-0799
Q5, Q115
Not Used
P1500 Transformer
TT-1456
Line Fuse
Fuse, 4A Slo Blo
FS-004SB
Parts List Modifications for P1500U 120VAC, 60Hz
European Linecord
FA-1464
Fuseholder Cup 5x20mm FS-1125
1.25A Slo Blo 5x20mm FS-1474A
230V Transformer
TT-1457B
Parts List Modifications for P1500CE
European Linecord
FA-1464
Fuseholder Cup 5x20mm FS-1125
2.5A Slo Blo 5x20mm
FS-1541A
230V Transformer
TT-1532B
Parts List Modifications for P3000CE
!
!
!
!
!
!
!
!
!
!
!
