Hasbro Alarm Clock Micro Music Player User Manual

Alarm clock micro music player instruction, Playing a hitclip

Playing a HitClip

Setting Time

Setting and using Alarm

Battery Installation

Front

Actual Size =148mm (W) X 210mm (H)

1. Per diagram, unscrew battery door lock.

2. Insert 4 new AAA batteries.

3. Replace battery door and tighten screw.

To ensure proper function

- Do not mix old and new batteries.
- Do not mix alkaline, standard (carbon zinc), or

rechargeable batteries (nickel-cadmium).

- Battery installation should be done by an adult.
- Non-rechargeable batteries are not to be recharged.
- Rechargeable batteries are to be removed from the

toy before being recharged (if removable).

- Rechargeable batteries are only to be charged under

adult supervision (if removable).

- Only batteries of the same or equivalent type as

recommended are to be used.

- Batteries are to be inserted with correct polarity. (see

engraving on back of alarm)

- Exhausted batteries are to be removed from the toy.
- The supply terminals are not to be short-circuited.

1. Slide the mode switch, located on the right hand

side of the clock, to the SET TIME position.

2. Press the hour button, on the front of the clock, until

the correct hour appears on the screen.

3. Press the minute button, on the front of the clock,

until the correct minute appears on the screen.

4. Return the mode switch to the TIME position after

you have finished.

1. Remove the clip and string from the HitClip Single.

2. Slide HitClip Single into Alarm Clock.

3. Press the RELEASE button at the top of the clock
to the down position and rotate the blue wheel until
the clip you would like to listen to is at the top.
Note: Do not rotate if button is up, damage will occur!

4. Press the RELEASE button again, so that it is in the

up position and the HitClip is secured.

5. Press the PLAY button to start and stop music.

1. Slide the mode switch, located on the right hand

side of the clock, to the SET ALARM position.

2. Press the hour button, on the front of the clock, until

the desired hour appears on the screen.

3. Press the minute button, on the front of the clock,

until the desired minute appears on the screen.

4. Return the mode switch to the TIME position after

you have finished.

5. To activate the alarm, slide the mode selector on the

front of the alarm to the HitClip alarm position to
awaken to your favorite HitClip, or to the buzz position
to awaken to a buzzing alarm.
Note: Please make sure that you follow all instructions
below within “Playing a HitClip” in order to wake to
a HitClip Single.

6. When the alarm goes off, you can press the

SNOOZE button to reset the alarm for 4 minutes.

Note: The SNOOZE button will not operate, if you are
using a Yahoo! HitClips Downloader Recordable Chip.

7. To deactivate the alarm, slide the mode selector on

the front of the alarm to the ALARM OFF position.

8. Press the LIGHT button to view the clock when dark.

Ages 5 & Up
Item No. 02008

Alarm Clock
Micro Music Player
Instruction
