Installation instructions, Fig. 4 fig. 5 – Hotpoint BS41X User Manual
Page 31
31
INSTALLATION INSTRUCTIONS
Double Pole
Control Switch
Single Oven
in tall
Cabinet
585mm max
578mm if cooker
trim is to
overlap
top edge
of shelf
*excluding pipes
and other
projections
6mm
2
Cable if Hotplate
fitted
Conduit Box
4mm
2
Cable if hob fitted
adjacent to oven
4mm
2
Cable
to Oven
Refer to Electrical Installation
560mm min
574mm max
*550mm
Fig. 4
Fig. 5
