Hafler 0915P - Manual (Page 9)

AC LINE VOLTAGE
RATING
UNSWITCHED
OUTLET*
OUT 2
TAPE
VIDEO
CD
PHONO CHASSIS
OUT
1
REC OUT
AUX 2
TUNER
PHONO/AUX
1
GROUND
LINE CORD CONNECTOR
SWITCHED OUTLETS
OUTPUTS
INPUTS
TOP ROW
-
RIGHT CHANNEL
BOTTOM ROW
-
LEFT CHANNEL
MC/MM SWITCH
(PHONO OPTION ONLY)
IN-MOVING COIL
OUT
-
MOVING MAGNET
915 PREAMPLIFIER REAR PANEL VIEW
*100-l
20 VAC UNITS ONLY.
200-240 VAC UNITS ARE WITHOUT CONVENIENCE OUTLETS.
