HSM 225.2 - Manual (Page 6)

HSM 225.2 Paper shredder
10 english 0510
Declaration of Conformity
Machinery directive 98 / 37 / EG
EMC directive 89 / 336 / EWG
Low voltage directive 73 / 23 / EWG
The manufacturer HSM Pressen GmbH + Co. KG, Bahnhofstraße 115, D-88682 Salem declares herewith, that the paper
shredders HSM 225.2 aboved mentioned correspond with the EC Machine Directive including all relevant modifi cations.
Applied standards and technical specifi cations:
• EN 55014-1:2000 + A1:2001 + A2:2002 • EN 61000-4-4:1995 + A1:2001 + A2:2001
• EN 55014-2:1997 + A1:2001 • EN 61000-4-5:1995 + A1:2001
• EN 61000-3-2:2000 • EN 61000-4-6:1996 + A1:2001
• EN 61000-3-3:1995 + A1:2001 • EN 61000-4-11:1994 + A1:2001
• EN 61000-4-2:1995 + A1:1998 + A2:2001 • EN 60950-1:2001
• EN 294:1992
Salem, 01.04.2005
Rolf Gasteier - Technical Director
Machine type inspection for compliance with the requirements of the EC Machine Directive was carried out by the „Admi-
nistration“/Inspection Authority Committee of Experts, Subject Area „Offi ce Machines and Devices“, on the premises of the
Verwaltungs-Berufsgenossenschaft, Deelbögenkamp 4, D-22297 Hamburg. This inspection authority is the authority respon-
sible in accordance with Annex V of the EC Machine Directive.
9. Technical Data
* HSM-specifi cation
Technical and optical modifi cations reserved
Cutting type Strip cut Cross cut
Shred size (mm) 5.8 3.9 3.9 x 40 1.9 x 15 0.78x11 1 x 5
Sa fe ty ra ting DIN 32757 – 1 2 2 3 4 5 Level 6*
Cutting ca pa ci ty (sheets), DIN A4 70 g/m 2
80 g/m 2
40 - 42
32 - 33 31 - 33
25 - 27 25 - 27
20 - 22 17 - 19
12 - 14 10 - 11
7 - 9 7 - 8
6 -7
Weight 42 kg 45 kg 48 kg
Noise level (Idle running/ load) 56 dB(A) / 62 dB(A) 56 dB(A) / 70 - 73 dB(A)
Cutting speed 126 mm/s 135 mm/s
Lo ading width 300 mm
Voltage 230 V, 50 Hz
100 V, 50/60 Hz – 115 V, 60 Hz
Power for the maximum number of sheets 1400 W
Dimensions W x D x H (mm) 500 x 420 x 895
Volume of shredded material bag 105 l
