Set up – Husqvarna BCZ3205DL User Manual
Page 9
GB-9
G
B
BCZ3205DL / BCZ3205DW
6. Set up
4
6
5
10
1
11
12
8
7
9
BCZ3205DL
BCZ3205DL
BCZ3205DL
BCZ3205DW
BCZ3205DW
BCZ3205DW
BCZ3205DW
3
14
15
16
17
18
19
20
13
2
A Package contains the items as illustrated.
(1) Unit (BCZ3205DL)
(2) Unit (BCZ3205DW)
(3) Hip pad
(4) Band (BCZ3205DW)
(5) Spacer
(6) Screw
(7) Handle (BCZ3205DL)
(8) Cutting attachment guard
(9) Guard skirt
(10) Harness (BCZ3205DL)
(11) Harness (BCZ3205DW)
(12) Trimmer head
(13) Blade
(14) Cover
(15) Blade cover
(16) Hexagon socket (S16/S17) with torx driver (T-27)
(17) Bar ( 4.5)
(18) Spanner (S8/S10)
(19) Screw driver
(20) Owner’s manual
