ELECTRICAL SUPPLY
Standard electrical supply for all Combi-Steamers is 208-240 volt, 3 phase, 50-60 Hz.
NOTE: The power connections are located behind the service door (see section 5-3).
Each unit requires a separate fused service according to the following table: (3 phase only)
Model
Voltage
Phase
Amps
Load
CSL/M/B-6
208V
3
27
9.6KW
CSL/M/B-6
208V
1
46
9.6KW
CSL/M/B-6
240V
3
27
9.6KW
CSL/M/B-6
240V
1
40
9.6KW
CSL/M/B-10
208V
3
52
18.6KW
CSL/M/B-10
240V
3
45
18.6KW
CSL/M/B-1020
208V
3
88
31.5KW
CSL/M/B-1020
240V
3
76
31.5KW
CSL/M/B-20
208V
3
103
37.2KW
CSL/M/B-20
240V
3
90
37.2KW
CSL/M/B-40
208V
3
175
63KW
CSL/M/B-40
240V
3
152
63KW
NOTE: When the oven is installed it must be electrically grounded in accordance with local codes, or in the absence of local
codes, with the National Electric Code, ANSI/NFPA 70-1990.
NOTE: All connections must comply with the oven data plate. A separate fused disconnect switch or circuit breaker
(not furnished) MUST be installed in the electrical supply line FOR EACH OVEN!
NOTE: The electrical diagram is located behind the service door.
The electric supply terminal block, located behind the service door, is clipped on a mounting rail which is attached to the
frame of the unit. The three phases of the power cord are connected to the three gray colored terminals. Ground is con-
nected to the yellow-green terminal.
NOTE: The phase sequence does not have to be observed because of the automatic reversing action of the fan motor.
CHANGES IN VOLTAGE
To change voltages of the Combi-Steamers (ex: 208 to 240 volt) the following has to be changed:
1) Air and steam elements
2) Contactor LS5
3) CSM and CSL units - the wires on the control panel transformer and the interior light transformer must be switched to
the correct voltage terminals.
Do Not use conduit as a supply ground, or electrical shock could result.
