NWXR473EVWW—Hotpoint 6.0 Cu. Ft. Extra-Large Capacity Electric Dryer

Specification Revised 8/99

Dryer Dimensions (in inches)

36

42

27

2

3-1/2

2-1/2

25-1/2

Side View

Rear View

8-1/2

28-1/4

23-1/2

11-1/2

Exhaust Options:
4-way via rear, right, left and bottom.

Circuit Requirements:
An individual, properly-grounded branch circuit, protected by a
30-amp circuit breaker or a time-delay fuse, is required.

Electric Dryer Rating:
208/240V, 3-wire, 5600W, 60Hz, 30 Amp

Installation Information: For complete information, see installation
instructions packed with product for current dimensional data.

R

Listed by
Underwriters
Laboratories
