SAFETY PRECAUTIONS
DECALS Continued.
HEIZKORPERDECKELENTFERNENERSTWENNDERMOTORKUHLIST.
ONLYREMOVE RADIATORCAPWHEN ENGINEISCOOL.
VERWIJDERDE RADIATORDOPPASNADATDE MOTORISAFGEKOELD.
ILFAUTTOUJOURSATTENDRELE REFROIDISSEMENTDUMOTEUR
AVANTDERETIRERLE BOUCHONDURADIATEUR.
70-13-073 REV (.0.)
Decal - Jacking / Support Point Part No: 70-13-072
Location: Front Axle - 2 Points
Rear Towing Eye
a) Jacking and Support Point
Decal - Engine Fan / Radiator Part No: 70-13-073
Location: Engine Fan Cowl
a) Danger of Severing Fingers
b) Caution
c) Warning - Hot Surfaces
Decal - Tyre Pressure Part No. 950832
Location: LH/RH Chassis - 4 Places
a) Mowing
b) Road Travel
Decal - Diff Lock / Control Pedal Part No: 924812
Location: Centre Platform.
a) Differential Lock
b) Depress to engage Diff-lock
c) Release to Dis-engage Diff-lock
d) Forward Speed & Directional Control
e) Reverse Speed & Directional Control
950832 Rev.2
0.7 BAR
10 PSI
1.4 BAR
20 PSI
1.13 1.13
a
a b c
a
b
924812 REV.(0)
a
b
c
d
e
