Speaker Wires

Factory Grommet

Inner Metal Door Panel

Wire Routing

COMPONENT MOUNTING PROCEDURES

Door Mount

Inner Metal Door Panel

Interior Door Panel

Tweeter

Speaker Screws

Speaker Grill

Speaker

Tweeter Retaining Clip
