Page 9
7
CONTROLS & FEATURES
COMPONENT & CONTROL LOCATIONS
Use this illustration to locate and identify frequently used controls.
REAR
DISCHARGE
GUARD
MULCHING PLUG
BLADE CONTROL
LEVER
FUEL VALVE
SPARK PLUG CAP
FUEL TANK CAP
CUTTING HEIGHT
ADJUSTMENT LEVERS
HEIGHT
ADJUSTMENT
THROTTLE
LEVER
HANDLEBAR
LOCKING
KNOB (2)
AIR CLEANER
LEVER
MUFFLER
OIL FILLER CAP
STARTER
GRIP
ROTO-
STOP®
SMART DRIVE™
CARBURETOR
LEVER
GRASS
BAG
CUTTING
CONTROL
