MAXI-140
8. To remove the fluorescent lamp, disconnect
the two individual connectors from each end.
9. Remove from holding clips.
10. Replace the lamp.
11. Reassemble in reverse order.
12. Plug the unit in. Turn on light switch.
13. Allow the unit to run for at least
30 minutes before stocking with fresh product.
LED (Interior Lighting)
LED light tube must be replaced by a light
tube of the same size dimension and wattage as
the original. Always unplug unit before
replacing LED light strip. Restocked beer
may freeze.
1. Follow steps 1 through 7 of Fluorescent
Lamp Replacement.
2. Disconnect the LED connector.
3. With a screwdriver, loosen, but do not
remove, the LED lighting bracket from one
side only.
4. Rotate loosened lighting bracket and remove
LED light tube.
5. Replace by positioning the LED light tube
with electrical wires to the right-hand side
closest to slot. Do not wrap wires around the
LED light tube. Route the electrical wires
through the slot before re-connecting.
6. Reassemble in reverse order.
7. Plug the unit in. Turn on light switch.
8. Allow the unit to run for at least
30 minutes before stocking with fresh product.
Two individual connectors
LED lighting bracket.
LED connector
Bracket
Route electrical cord
through here
Replacement LED tube
must be at same angle
